Refurbished Cisco C9500
Specifications
- C9500-16X-A V02
- 16-port 1/10 Gigabit Ethernet
- 1x NIM Blank
- Switching Capacity - Up to 480 Gbps
Cisco IOS XE Software, Version 17.03.05
Cisco IOS Software [Amsterdam], Catalyst L3 Switch Software (CAT9K_IOSXE), Version 17.3.5, RELEASE SOFTWARE (fc2)
Technical Support:
Copyright (c) 1986-2022 by Cisco Systems, Inc.
Compiled Wed 09-Feb-22 10:41 by mcpre
Cisco IOS-XE software, Copyright (c) 2005-2022 by cisco Systems, Inc.
All rights reserved. Certain components of Cisco IOS-XE software are
licensed under the GNU General Public License ("GPL") Version 2.0. The
software code licensed under GPL Version 2.0 is free software that comes
with ABSOLUTELY NO WARRANTY. You can redistribute and/or modify such
GPL code under the terms of GPL Version 2.0. For more details, see the
documentation or "License Notice" file accompanying the IOS-XE software,
or the applicable URL provided on the flyer accompanying the IOS-XE
software.
ROM: IOS-XE ROMMON
BOOTLDR: System Bootstrap, Version 16.12.2r, RELEASE SOFTWARE (P)
Switch uptime is 7 minutes
Uptime for this control processor is 8 minutes
System returned to ROM by PowerOn
System image file is "flash:packages.conf"
Last reload reason: PowerOn
This product contains cryptographic features and is subject to United
States and local country laws governing import, export, transfer and
use. Delivery of Cisco cryptographic products does not imply
third-party authority to import, export, distribute or use encryption.
Importers, exporters, distributors and users are responsible for
compliance with U.S. and local country laws. By using this product you
agree to comply with applicable laws and regulations. If you are unable
to comply with U.S. and local laws, return this product immediately.
A summary of U.S. laws governing Cisco cryptographic products may be found at:
If you require further assistance please contact us by sending email to
Technology Package License Information:
------------------------------------------------------------------------------
Technology-package Technology-package
Current Type Next reboot
------------------------------------------------------------------------------
network-advantage Smart License network-advantage
dna-advantage Subscription Smart License dna-advantage
AIR License Level: AIR DNA Advantage
Next reload AIR license Level: AIR DNA Advantage
Smart Licensing Status: Registration Not Applicable/Not Applicable
cisco C9500-16X (X86) processor with 1331284K/6147K bytes of memory.
Processor board ID FOC2639Y3XK
1 Virtual Ethernet interface
24 Ten Gigabit Ethernet interfaces
2 Forty Gigabit Ethernet interfaces
2048K bytes of non-volatile configuration memory.
16777216K bytes of physical memory.
1638400K bytes of Crash Files at crashinfo:.
11264000K bytes of Flash at flash:.
Base Ethernet MAC Address : 34:1b:2d:3f:6c:80
Motherboard Assembly Number : 73-18709-01
Motherboard Serial Number : FOC26380WJG
Model Revision Number : E0
Motherboard Revision Number : E0
Model Number : C9500-16X
System Serial Number : FOC2639Y3XK
CLEI Code Number :
Switch Ports Model SW Version SW Image Mode
------ ----- ----- ---------- ---------- ----
* 1 26 C9500-16X 17.03.05 CAT9K_IOSXE INSTALL
Switch#show inv
Switch#show inventory
NAME: "c95xx Stack", DESCR: "c95xx Stack"
PID: C9500-16X , VID: V02 , SN: FOC2639Y3XK
NAME: "Switch 1", DESCR: "C9500-16X"
PID: C9500-16X , VID: V02 , SN: FOC2639Y3XK
NAME: "Switch 1 - Power Supply A", DESCR: "Switch 1 - Power Supply A"
PID: PWR-C4-950WAC-R , VID: V01 , SN: DCI2616M13X
NAME: "Switch 1 - Power Supply B", DESCR: "Switch 1 - Power Supply B"
PID: PWR-C4-950WAC-R , VID: V01 , SN: DCI2616M0Z3
Switch#show env
Switch#show environment all
Switch FAN Speed State
---------------------------------------------------
1 1 38240 OK
1 2 38240 OK
1 3 38240 OK
1 4 38240 OK
1 5 38240 OK
FAN PS-1 is OK
FAN PS-2 is OK
Switch 1: SYSTEM TEMPERATURE is OK
Inlet Temperature Value: 31 Degree Celsius
Temperature State: GREEN
Yellow Threshold : 46 Degree Celsius
Red Threshold : 56 Degree Celsius
Outlet Temperature Value: 35 Degree Celsius
Temperature State: GREEN
Yellow Threshold : 105 Degree Celsius
Red Threshold : 125 Degree Celsius
Hotspot Temperature Value: 52 Degree Celsius
Temperature State: GREEN
Yellow Threshold : 105 Degree Celsius
Red Threshold : 125 Degree Celsius
SW PID Serial# Status Sys Pwr PoE Pwr Watts
-- ------------------ ---------- --------------- ------- ------- -----
1A PWR-C4-950WAC-R DCI2616M13X OK Good n/a 950
1B PWR-C4-950WAC-R DCI2616M0Z3 OK Good n/a 950
Switch#Show license summary
License Usage:
License Entitlement Tag Count Status
-----------------------------------------------------------------------------
network-advantage (C9500 Network Advantage) 1 IN USE
dna-advantage (C9500-16X DNA Advantage) 1 IN USE
Condition
This item has been classed as being in Grade A Condition, fully working with only minor signs of use.
Included Accessories
- Power Cord
05122023
(1107)
| SKU | 1107 |
| Barcode # | 20000000047929500 |
| Brand | Cisco |
| Model | 9500 16X A |
